AMF Thermatex
Acoustic

View product related downloads

AMF THERMATEX Acoustic is a 19 mm thick ceiling tile made from a specially perforated mineral board and an acoustic fleece facing. The perforations provide excellent sound absorption while the fleece offers a smooth, elegant surface finish. The combination of high density, bio-soluble mineral wool with clay and starch provides excellent physical characteristics, particularly for acoustic performance. Our AMF Acoustic Range carries the Declare label.

System
Exposed Grid System, demountable ceiling  |  Free span system, with exposed or concealed suspension  |  Bandraster system, with exposed or concealed suspension
Dimensions
600 x 600 mm, 625 x 625 mm, 1200 x 600mm
Thickness / Weight
19 mm (c. 4.6 kg/m²)
Colour
White similar to RAL 9010
Edge details
SK, VT 15/24 on request, AW, GN

Sound absorption
αw = 0.65H as per EN ISO 11654  |  NRC = 0.70 as per ASTM C 423-01
Sound attenuation
Dn,c,w = 38 dB as per EN 20140-9 (19 mm thickness)  |  Dn,c,w = 40 dB as per EN 20140-9 (semi-concealed planks)
Light reflectance
up to 85%
Thermal conductivity
λ = 0.052 – 0.057 W/mK as per DIN 52612
Humidity
up to 95 % RH
