BOSS
FyreBox

The BOSS FyreBox is revolutionising firestopping methods for large bundles of mixed services. Designed to allow large bundles of pipes and cables to all pass through one single fire rated enclosure, the  Fire Transit Box is the only tested and proven method of firestopping multiple services with such simplicity of installation and ease of compliance. Commonly used for apartment entry configurations above an entry door to an SOU, the Fire Box is also suited for service risers, shafts, plant areas and data rooms in a variety of residential, commercial and industrial buildings.

The new generation of BOSS FyreBox is now tested and approved to AS1530.4: 2014 and AS4072.1-2005 for 30, 60, 90 and 120 minute configurations on a larger variety of services than ever before. New approvals relate to a wider variety of wall, concrete slab &  floor / ceiling systems.

The BOSS FyreBox allows you to group various electrical, plumbing, HVAC+R services all through one easy to use and easily certified box. Because services trades don’t need to treat their services individually, risk is removed from using incorrect products or not having them installed correctly.

1. Up to 2 hour fire rating (FRL -/120/120)
2. Up to Rw50 acoustic rating
3. Approved for a wide range of walls, concrete slabs & floor/ceilings
4. Wide variety of services and mixed combinations
5. Saves up to 90% of labour costs
6. Makes AS1851 periodic maintenance inspections simple and reliable
7. Services can be easily added after installation
8. Tested & approved to AS1530.4-2014 and AS4072.1-2005
9. Many typical apartment service configurations available
10. Large variety of electrical, plumbing & HVAC services certified

Easily fixed to the underside of concrete soffit before walls are built, or be installed into the wall during construction in a mid wall mount scenario. A range of fixing methods are available including retrofit options using equal angles. Recent additions to the range include retrofit options to concrete floor slabs and also ceiling approvals.

Once the box is installed, services simply “pass through” the box. There is no need to core individual penetrations for each service, or cutting any inserts, nor do you need to seal or treat every individual service. The unique Brush Seal allows services to be passed through the box at any time of construction, or even later after a project has been completed making it easier than ever for maintenance contractors and building managers to maintain fire compliance once the building is occupied.

HOW DOES IT WORK IN FIRE?

The BOSS FyreBox contains an advanced high pressure intumescent internally that upon getting exposed to high temperatures, expands to create a superior performing fire seal. Coupled with the unique Brush Seal that is designed to make the installation and compliance simple, ultimately leading to an industry-leading level of protection.

Suitable for various projects and applications:

• Apartment entry walls and above doorways in high-rise residential apartments
• SOU entry walls in Hotels and Student Accommodation Buildings
• Computer rooms and data centres
• Corridors and tunnels where services pass through multiple fire rated walls
• Risers and shaft walls
• Industrial applications with “multi-service” requirements
• Office tower passive fire stopping and fire rating.
• Use in concrete floor slabs

Certified services include:

• Steel sprinkler pipes up to 60mm Diameter
• Copper pipes – Lagged and Unlagged up to 40mm
• PEX Water pipes up to 32mm
• PEX/AL/PEX Gas Pipes up to 32mm
• A/C Lagged copper Paircoil pipes for HVAC (Up to 13mm/19mm)
• uPVC pipes and conduit up to 32mm
• Mains and Sub Mains Power cables
• TPS power cables
• Aluminium Core Power Cables
• Data Cables including CAT6 & CAT5E
• Security, Intercom, Fire and EWIS cables
• Coax TV (MATV / CATV / SMATV) cables.
• NBN Cables and Conduit
• PP Pipes up to 32mm
• HDPE Pipes up to 32mm
• PB Pipes up to 32mm

Certified substrates include:

• Fire Rated Plasterboard wall systems
• Shaftliner / Shaftwall systems
• Concrete / Masonry Walls
• AAC / Hebel Walls
• Dincel Walls
• AFS Walls
• BOSS Batt
• Speedpanel & Korok Walls
• CLT (Cross Laminated Timber) Walls
• Concrete Floor Slabs
• Plasterboard Ceilings

Please check the relevant fire certification to ensure the services, substrates and configurations meet your fire rating requirements.
For more information call our Technical Services team to discuss your project requirements.

Detailed Building Product Information Datasheets Are Available from www.bossfire.com.au
