Rondo DUPLEX is one Stud that does the job of two.
It’s perfect for door openings and glazing in internal wall framing applications where you typically need to install a boxed stud configuration. Less product to install means much quicker installations, delivering you with the all-important labour cost savings.
It can also be used as a Wall Stud where the use of standard Steel Studs would require installation at closer centres. In this application, DUPLEX Stud® provides additional load capacity and reduces not only the material cost but labour cost as well.
Partnered with new Fixing Brackets and existing medium gauge Slotted Deflection Head Track, the Rondo DUPLEX Stud System® is the perfect addition to the Rondo family of Wall Framing Systems.[/vc_column_text][/vc_column_inner][vc_column_inner width="1/2"][vc_gallery type="flexslider_slide" interval="3" images="6405,6406,6407" img_size="540x390" el_class="productzoom-icon"][/vc_column_inner][/vc_row_inner][vc_row_inner content_placement="middle" el_class="properties-section py-100"][vc_column_inner width="1/2"][vc_single_image image="6406" img_size="full"][/vc_column_inner][vc_column_inner width="1/2"][vc_column_text el_class="image-width-text-content"]SUITABLE FOR
Replacing single boxed stud to support door frames
Internal glazing and door jambs
Access openings for services within the wall framing
Internal Load Bearing Walls by Rondo Engineered Design
Incorporation into standard Rondo narrow flange steel internal wall framing
SPECIAL FEATURES
Greater load capacity than standard narrow flange wall systems negating the necessity for boxed or back to back configurations or the reducing of Stud centres
Integrated with the Rondo medium gauge Slotted Deflection Head Track providing better, positive connections
Like all Rondo Steel Studs, DUPLEX can be manufactured in custom lengths to suit your project
DUPLEX Studs are made from G2 grade steel for optimum cost efficiency
DUPLEX Studs are made from steel with a minimum gal coating of Z275
Higher walls can be achieved before noggings are required
Central rib on fixing flange allows for vertical alignment of wall linings
Rondo design wizard assists to determine maximum ceiling spans, wall heights, product estimation, radius calculations and seismic design. Visit the Rondo website here.Detailed Building Product Information Datasheets Are Available from www.rondo.co.nz[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_row_inner disable_element="yes" el_id="profile_options" el_class="releated_products"][vc_column_inner][vc_column_text el_class="bg-section-grey py-100"]
