Gyprock Flexible is a 6.5mm plasterboard sheet with an enhanced gypsum core in a heavy duty liner paper that enables the board to bend to a small radius.
This plasterboard is installed in two layers for increased strength and the long edges of the panels are recessed for flush jointing to a smooth, continuous surface.
»Curved walls and ceilings
»Freeform bulkheads and features
Gyprock Flexible Plasterboard is manufactured to a 6.5mm thickness in 1200mm wide panels that are 3600mm long.
Gyprock Flexible Plasterboard is typically installed in two layers for a 13mm thick final lining thickness allowing it to match other lining thicknesses in commercial contruction.
This installation can accommodate a 250mm radius design for a convex curve and 450mm radius for a concave curve.
Gyprock Flexible is available in the following sizes:
|Edge Profiles||Recessed Edge for regular jointing, Recessed Edge/Square Edge for low profile architectural mouldings|
Gyprock Flexible is manufactured by CSR Gyprock in Australia to stringent product specifications.
Transportation and manual handling: Refer to the Gypsum Board Manufacturers of Australia (GBMA) website for recommended OH&S practices.
Storage: Protect plasterboard and cornice from weather and moisture. Avoid products sagging by storing horizontally, supported on a level platform or full-width support members spaced at max. 600mm centres.
Safety Data Sheets are important documents in the construction industry and assist in the continuing focus on occupational health and safety on and off sites.
|Nominal Thickness||6.5mm ± 0.5mm|
|Nominal Widths||1200 ± 3mm|
|Nominal Lengths||3600mm ± 5mm|
|Squareness||Cut ends ± 3mm in the width of the board|
|Nominal Board Weight*||4.3kg/m2|
|Thermal Resistance||0.03 m2K/W|
|Fire Hazard Properties∆||Group No = 1
SMOGRARC <100 m2/s2
|Combustibility◊||Plasterboard may be used wherever a non-combustible material is required.|
|Total Recycled Content||10.2%|
* Subject to reasonable manufacturing variance
∆ In accordance with AS ISO 9705 and AS 5637.1
◊ In accordance with NCC2022 Vol 1 Clause C2D10(6)(a) and NCC2019 Amdt1 Vol Clause C1.9(e)(i).
