The need to allow for large amounts of vertical deflection, very high plenum heights and intense services has led to the engineered solution TRACKLOK® FLAT. Utilising the strength of the TRACKLOK® design and the ability to brace one wall off another, TRACKLOK® FLAT is revolutionary. Ensuring seismic separation, providing ceiling clearance and featuring unique adjustability to clear troffer lights and services – TRACKLOK® FLAT is an elegant, yet robust solution.
FEATURES AND BENEFITS
Unique design allows for unlimited vertical deflection
Unit mitigates service clashes
Unique design mitigates the need to account for inter story drift
Tested with head track and full wall construction to provide confidence
Tested under ULS and SLS loads to ensure longevity of performance
Applicable to all seismic zones and all seismic loads
Patented low profile connection bolt allows for glazing clearance
Height adjustment of unit allows clearance from troffer lights and services
Allows for 64mm and 92mm boxed bracing to be used reducing waste on site
COMPLIANCE
Complies to and provides compliance with AS/NZS 1170 and AS/NZS 4219.
Provides compliance with NZ Building Code Clause B1 – Structure, B2 Durability, F2 – Hazardous Building Materials.
Contributes to compliance with NZ Building Code Clause F6 – Visibility in Escape Routes, Clause D1 – Access Routes.
APPLICATIONS
Importance Level 2, 3 and 4 Buildings
Hospitals
Commercial Interiors
Schools
Product Downloads
Detailed information is provided on product specific datasheets referenced below.
Bringing an existing fit out up to seismic code, adding value to your clients existing fit out, or create efficiencies by bracing and lining at the same time.
