AMF Thermatex Alpha One is a mineral suspended ceiling tile which provides high sound absorption values. With a strong white acoustic fleece, Thermatex Alpha One offers a smooth, elegant surface finish. The combination of bio-soluble mineral wool with clay and starch provides excellent physical characteristics. Our AMF Acoustic Range carries the Declare label.

System
Two way exposed grid system

Dimensions
600 x 600 mm, 1200 x 600mm (other sizes available on request)

Thickness / weight
24 mm (c. 3.3 kg/m²)

Colour
White similar to RAL 9010

Edge details
SK, VT 24 (other profiles available on request)

Sound absorption
NRC = 1.00 as per ASTM C 423

Sound attenuation
CAC = 24 dB as per ASTM E413-10

Fire resistance
Group 1-S
(as per ISO 5660 Parts 1 and 2)

Light reflectance
up to 88%

Thermal conductivity
λ = 0.040 W/mK as per EN 12667

Humidity
up to 95 % RH

Clean room
Class 4 as per ISO 14644-1
