AMF Thermatex Acoustic Medical – The ceiling system for healthy environments.

Key Performance

Environment

System
Two way exposed grid system

Dimensions
600 x 600 mm, 1200 x 600mm (other sizes available on request)

Thickness / weight
19 mm (c. 5.0 kg/m²)

Colour
White similar to RAL 9010

Edge details
Board, Tegular 24, Tegular 15/90

Sound absorption
NRC = 0.70 as per ASTM C 423

Sound attenuation
CAC = 40 dB as per ASTM E413-10

Sound absorption
NRC = 0.70 as per EN ISO 354 & EN ISO 11654

Sound attenuation
CAC = 40 dB as per EN ISO 717-1

Fire resistance
Conforms with NCC Spec. C1.10 as tested to AS 5637.1:2015 – Group 1, and ISO 5660 – Group 1 – S

Light reflectance
up to 88%

Thermal conductivity
λ = 0.35 m2K/W as per EN 12667

Humidity
up to 95 % RH

CleanRoom
ISO 3 Clean Room performance with paint sealed edges
