Rondo Steel Stud &
Track Wall Framing System

The Rondo Steel Stud Drywall Framing System provides a durable, practical and lightweight structure for internal plasterboard walls and for specific external walls. The availability of various sizes, complimentary components such as nogging tracks, curved tracks and special cleats ensure Rondo Stud and Track wall systems are available to suit almost all situations.

Designed to not only be stronger but safer, our range of Hemmed Track sections and 51mm (401) and 76mm (403) Wall Stud helps reduce handling injuries on site. The hemmed return lip increases rigidity, preventing unwanted rotation as well as eliminating sharp edges.

The vertical rib in the stud face allows the wall linings to be placed centrally, ensuring easier and faster fixing, while the deeper knurling provides better screw location and retention. What’s more, our studs lock perfectly into each other, creating the best boxed stud profile in the market.

Rondo Steel Stud Drywall Framing Systems comply with all relevant Building Codes for fire-rated, acoustic, seismic and load bearing requirements.

Rondo 0.50bmt, 0.55bmt and 0.75bmt Wall Studs have bell mouthed service holes. Being bell mouthed with no protruding sharp edges eliminates the need for fitting grommets for electrical cabling. Punched round holes are processed at designated centres along our 1.15bmt Wall Studs.

NOGGINGS FOR YOUR INTERNAL STEEL STUD WALL

• When it comes to selecting a nogging for your internal wall framing, we have a large range available with each of them designed to suit a specific application.
• The continuous nogging track can be installed during the steel stud framing and can be fitted to the stud framing in one length
• The double-punched Nogging Track suits a wider stud arrangement such as boxed studs, or the Duplex and Maxijamb Studs
• The Fastfix nogging suits any typical stud application, whether its boxed, back to back or staggered stud, it can also be used with Duplex and QuietStud profiles.

SUITABLE FOR

• Non-load and load bearing (by design) partition walls
• Steel Stud Ceiling Systems
• Window and Door Jambs
• Non-Fire Rated and Fire-rated Systems
• Acoustic Wall Systems (by design)
• External Wall systems (by design)
• Light Weight Floor Joists
• Bulkheads
• Seismic Wall System by design

SPECIAL FEATURES

• Available in custom lengths.
• Majority of Stud and Track is hemmed for safety and increased strength, preventing unwanted rotation.
• MAXIframe External Wall Framing System made from 1.2BMT G500.
• Flexible Track available for curved walls.
• Manufactured from BlueScope Steel with a minimum coating of Z275.
• Profiles widths range from 51 to 150mm, and gauges from 0.50 to 1.15BMT.
• Bell mouthed service holes on 0.50bmt, 0.55bmt and 0.75bmt Wall Studs mitigate damages to services.

Rondo have a wizard that can help you determine maximum ceiling spans, wall heights, product estimation, radius calculations and seismic design.
Visit the Rondo website here.

Detailed Building Product Information Datasheets Are Available from www.rondo.co.nz
