The Rondo WALK-ABOUT Trafficable Ceiling System is a steel grid system that is versatile, easy to assemble and offers a cost effective design. Providing a framework onto which a trafficable platform can be installed in the plenum area above ceilings for accessing mechanical and electrical services.
Using standard Rondo Steel Stud profiles with purpose made joiners and clips; the WALK-ABOUT Trafficable Ceiling System is suspended from the structure above to provide a safe and secure access to services whilst simultaneously providing a support for the ceiling beneath.
The WALK-ABOUT Ceiling System seamlessly integrates with the Rondo KEY-LOCK® Concealed Suspended Ceiling System and Rondo DUO® Exposed Grid Ceiling System and can also be specified for use in seismic designs. However, it is important to note that seismic activity varies significantly so it is recommended to contact us for detailed technical design advice.
Once WALK-ABOUT Ceiling System is constructed, a walking platform can be installed. Although Rondo does not manufacture or supply systems for the construction of walking platforms, our Technical Design Team can still assist you in determining your requirements to suit your WALK-ABOUT Ceiling design.
What is the walk-about ceiling system suitable for?
Steel Ceiling Grid Systems
Concealed, flush ceiling finishes
Supporting a walking platform in the ceiling plenum
Supporting of direct fixed or fully suspended ceilings beneath
What you’ll like about our ceiling system
It seamlessly integrates with Rondo KEY-LOCK® Concealed Suspended Ceiling System and Rondo DUO® Exposed Grid Ceiling Systems
Basic version of the WALK-ABOUT Ceiling Design will accept a 1.1kN point load with a deflection limit of L/360
Available for Seismic Designs
Detailed Building Product Information Datasheets Are Available from www.rondo.co.nz
Product Downloads
Detailed information is provided on product specific datasheets referenced below.
Rondo WalkAbout Trafficable Ceiling System ManualPDFPreviewDownload
Rondo Walkabout Trafficable Ceiling System ComponentsPDFPreviewDownload
