Boss Rainscreen Ventilated Fire Barrier

Rainscreen Ventilated Fire Barrier (RSVB) is developed to protect the building void between the outer rainscreen cladding/facade and the inner construction element. RSVB leaves a gap up to 50mm to allow the movement of air and moisture. The aluminium foil facings provide class ‘O’ rating and excellent resistance to smoke. A unique method of manufacture provides a resilient lateral compression required to ensure a tight fit.

The advantages of RSVB are as follows:



  • Fire Resistant testing to 60 & 120mins.
  • Air Permeability testing to 600Pa.
  • Suitable to close up to 50mm ventilation gap.
  • Voids up to 450mm wide.
  • Available in Pre-Cut Sections for ease of application with minimum waste to suit void size.
  • Superior Level of Sustainability.
  • Encased Fibre Migration for Air Plenium Use.
  • Free of halogens, asbestos, fibres, silica and non-toxic.
  • Brackets included in the pack.
  • Life expectancy of over 25 years.
  • Contributes to Green Building.
  • Softer feel, Odourless and Easy to Cut.
  • Light Weight.

Detailed Building Product Information Datasheets Are Available from www.bossfire.com.au
