TRACKLOK® for new builds, allows you to connect directly through the partition head, separating wall from ceiling. Tested to provide structural and seismic performance for internal non-structural walls and glazing lines. Utilises steel stud for bracing stock and 10-gauge wafer tech screws to attach bracing stock to the unit and soffit top connectors. Set out charts provide clear guidance for placement.
Utilised in IL2, IL3 and IL4 buildings.
KEY FEATURES
Secures partition walls and glazing lines, under ceiling to slab above
Designed to absorb seismic energy, reducing partition wall failure
Applicable to all seismic zones and all seismic loads
Meets or exceeds all national code requirements
Unique design for variable bracing stock to be utilised, reducing waste
Low profile allows installation in partition and glazing head tracks
Engineered to eliminate ceiling grid interaction and to protect warranty
Designed and tested to mitigate risk to life and property
STATEMENT OF BUILDING CODE COMPLIANCE
Load testing of the bracket assembly in accordance with AS/NZS1170.0:2002 has been carried out
Must be installed in compliance with standard industry practices and within the parameters of AS/NS1170.0:2002
NZBC DESIGNED TO COMPLY
B1 Structure
B2 Durability
F2 Hazardous Building Materials
Learn How Tracklok® Seismic Bracing Works
Product Downloads
Detailed information is provided on product specific datasheets referenced below.
Bringing an existing fit out up to seismic code, adding value to your clients existing fit out, or create efficiencies by bracing and lining at the same time.
